CPD China Top Brand 4ton Diesel Forklift with Engine





Description:

we can offer you customized service, the following items are optional: Container mast, for example, 2-stage full free mast of 3m, 3-stage full free mast of 4.5m/ 4.8m side shifter, fork positioner, longer forks, fork extension and all kinds of forklift attachment. For the details of customized configurations and options, please contact with us.

Standard Configuration

* Hydraulic Automatic Transmission.

* Shimadzu's Pump Valve, Eaton Pipe and NOK Hydraulic Cylinder Seals.

* Electric-hydraulic Directional Control Valve.

* The Casting-type Steering Axle which more than 8 years of service life than ordinary Welded Axle.

* The Maintenance Free Radiators adopt Germany Technology.

* Adopt Priority Steering System, which improve the work efficiency.

* Original Toyota Comfortable Seat with Armrest and Safe-belt, LED Light ect.

* Thicker reinforcing overhead guard protective device, ensure the safety.

* Middle muffler, more environmental.

Technical Parameter:

Type	CPD1030	CPD1530	CPD2030	CPD3030
Capacity(kg)	1000	1500	2000	3000
Lift Height(mm)	3000	3000	3000	3000
Fork Length(mm)	500	500	500	500
Min Ground Height(mm)	1070	1070	1070	1070
Manipulation	Steering Wheel
Tire	Solid Core Tire
Drive wheel dimensions	510mm	510mm	560mm	650mm
Full Load Travel Speed	15km /h	15km /h	15km /h	15km /h
Full Load Lifting Speed	200mm/Min.	200mm/Min.	200mm/Min.	200mm/Min.
Type of driver	Stepless speed regulation
Door Frame Angle	3-6	3-6	3-6	3-6
Full Load Climbing	15	15	15	15
Battery (Vol./Cap.) (V /Ah)	48/240	48/270	48/270	48/420
Reference Usage Time(h)	3	3	3.5	6
Driving Motor(kw)	4	4.2	5	8
Lifting Motor(kw)	3	3	5.5	5.5
Mini. outside Turning Radius	2000mm	2000mm	2100mm	2150mm
Dimension L×W×H(mm)	3380×1050×2100	3380×1050×2100	3450×1100×2100	3600×1160×2120
Net Weight(kg)	2200	2000	2100	2150
Lifting Height of Each Cap. Corresponding Height of Gantry	1600/2000/2500/3000/3500mm 2080/1600/1850/2080/2350mm





CPD China Top Brand 4ton Diesel Forklift with engine

Product Name	CPD China Top Brand 4ton Diesel Forklift with engine
Features	Good quality and low price
Service	OEM&ODM
Custom Design	Welcome
Sample Lead Time	5~40Days
Payment Terms	30% advance payment, the rest payment before delivery
Market	all over the world
Form of sale	Factory supply



Q1:How do you control the quality?
A:We have QC team comply with TQM,each step is in compliance to the standards.At the same time,they
will take photos and shoot video for you.

Q2:Why should I choose your company?
A:1,We have own logistics who cooperate different forwarders at the ports of destination.It's good for you
to do DDP or DDU.
A2:We have own warehouse at the ningbo port China.
If you want to mix disparate products to different stores,we can help you to finish the work when our
workers receive the goods from suppliers. New carton labels will be printed and new pallets with unique
IDs will be created.It will save labor cost for you.

Q3: Can you print our brand on the product?
A: Yes, Of course. It can make customer’s brand logo.

Q4: What is your terms of packing?
A: Generally, we pack our goods in neutral cartons. If you have legally registered patent, we can pack the
goods by your logo after getting your authorization letters.

Q5: What about the Wheel axle scales price?
A: We promise the Wheel axle scales price we offer is lowest if same application, only to enlarge the
market share.

Q6:What’s your company payment terms?
A:L/C at sight/ 30days, T/T 30%deposit 70% before shipment.

Q7:Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery. We have QC team comply with TQM,each step is in compliance
to the standards.
