Zhejiang, China
SAINTBOND
Mini0105
Weigh the weight of the weigher
Convert electrical signal to the force signal
2.0mV/V
50kg bathroom scale gml698 micro jewellery load cell sensor
Aluminum
1SET
Good quality and low price
OEM&ODM
Welcome
5~40Days
30% advance payment, the rest payment before delivery
Carton,0.35x0.3x0.2cm
50kg bathroom scale gml698 micro jewellery load cell sensor
Planar beam load cell,very low profile,matched output.Aluminum construction with surface anodized.Mainly for low profile infant and adult medical scale,low profile platform scales,personal scale,airport baggage scale,postal scales etc.
Rated Capacity: | 50Kg | Insulation resistance: | ≥2000MΩ |
Full Scale Output: | 1.0mV/V ± 0.15 | Temp. effect on span: | ±0.1%F.S/10℃ |
Non-linearity: | 0.05%FS | Temp. effect on zero: | ±0.05%F.S/10℃ |
Hysteresis: | ±0.05%F.S | Compensated temp. range: | -10~+40℃ |
Creep: | ±0.05%F.S/3min | Use temp. range: | -10~+40℃ |
Zero balance: | ±0.3%F.S | Excitation voltage: | 3~8V(DC) |
Input resistance: | 1000±10Ω | Safe overload: | 120%F.S |
Output resistance: | 1000±10Ω | Ultimate overload : | 150%F.S |
FAQ:
Q: Could you offer more information about the products, and quote a best price ?
A: Yes, certainly, we will send our product catalogue and company introduction for your reference.
You can choose one or some model, I will advice suitable one for you, also with best price details.
Q: Are you manufacture or trading company ?
A: We are manufacture, also have own export right under our export company. Welcome to visit our factory, check our quality and service.
Q: How long is your delivery time ? What's your payment terms ?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity. Payment terms is TT, LC, Cash, also can be negotiation with us.
Q: Your price is a little bit higher than my target, can you offer a better price ?
A: Yes, price can be negotiation, we try our best to meet your target, let's find a win-win solution, we always keep long term cooperation relations with customers.
50kg bathroom scale gml698 micro jewellery load cell sensor
Planar beam load cell,very low profile,matched output.Aluminum construction with surface anodized.Mainly for low profile infant and adult medical scale,low profile platform scales,personal scale,airport baggage scale,postal scales etc.
Rated Capacity: | 50Kg | Insulation resistance: | ≥2000MΩ |
Full Scale Output: | 1.0mV/V ± 0.15 | Temp. effect on span: | ±0.1%F.S/10℃ |
Non-linearity: | 0.05%FS | Temp. effect on zero: | ±0.05%F.S/10℃ |
Hysteresis: | ±0.05%F.S | Compensated temp. range: | -10~+40℃ |
Creep: | ±0.05%F.S/3min | Use temp. range: | -10~+40℃ |
Zero balance: | ±0.3%F.S | Excitation voltage: | 3~8V(DC) |
Input resistance: | 1000±10Ω | Safe overload: | 120%F.S |
Output resistance: | 1000±10Ω | Ultimate overload : | 150%F.S |
