Zhejiang, China
SAINTBOND Load Cell shackle
LS02W Load Cell shackle
Weighing
Resistance Sensor
Digital Sensor
Load Cell shackle
15 years experience on Load Cell
18650 rechargeable batteries or polymer batteries
2 Pcs
OEM&ODM
45 -50DAYS
15~30Days
3t~500t
Cheap price hot wireless telemetry stainless load cell shackle
Full Load Ton | Max. Proof Load Ton | Normal Size ‘A’ | Inside Length‘B’ | Inside Width ‘C’ | Bolt Dia. ‘D’ | Unit Weight(Kg) |
3 | 4.2 | 25 | 85 | 43 | 28 | 3 |
6 | 8 | 25 | 85 | 43 | 28 | 3 |
10 | 14 | 32 | 95 | 51 | 35 | 6 |
17 | 23 | 38 | 125 | 60 | 41 | 10 |
25 | 34 | 45 | 150 | 74 | 51 | 15 |
35 | 47 | 50 | 170 | 83 | 57 | 22 |
50 | 67 | 65 | 200 | 105 | 70 | 40 |
75 | 100 | 75 | 230 | 127 | 83 | 60 |
100 | 134 | 89 | 270 | 146 | 95 | 100 |
120 | 150 | 90 | 290 | 154 | 95 | 130 |
150 | 180 | 104 | 330 | 155 | 108 | 170 |
200 | 320 | 152 | 559 | 184 | 121 | 215 |
300 | 480 | 172 | 683 | 213 | 152 | 364 |
500 | 800 | 184 | 813 | 210 | 178 | 520 |
Wireless Load Links Typical Specifications:
Rate Load: | 1/2//3/5/10/20/30/50/100/200/250/300/500T |
Proof Load: | 150% of rate load |
Ultimate Load: | 400% F.S. |
Power On Zero Range: | 20% F.S. |
Manual Zero Range: | 4% F.S. |
Tare Range: | 20% F.S. |
Stable Time: | ≤10seconds; |
Overload Indication: | 100% F.S. + 9e |
Max. Safety Load: | 125% F.S. |
Battery Life: | ≥40 hours |
Battery Type: | 18650 rechargeable batteries or polymer batteries (7.4v 2000 Mah) |
Operating Temp.: | - 10℃ ~ + 40℃ |
Operating Humidity: | ≤85% RH under 20℃ |
Remote Controller Distance: | Min.15m |
System Range: | 500~800m (In Open Area) |
Telemetry Frequency: | 470mhz |
