Zhejiang, China
SAINTBOND Miniature Sensors
AM007 Miniature Sensors
Weighing
Resistance Sensor
Other
Miniature Sensors
5/15/40kG
Aluminum
IP65
≤10V
0.03
Welcome
OEM&ODM
1pcs per type per capacity
OEM & ODM Manufacture
China Manufacture Aluminum Single Point Miniature Sensors
Technical Parameter:
Model | AM007 | Temp.Effect on Output | ±0.02%F.S/10℃ |
Capacity | 5/15/40kG | Zero Output | ±0.08%F.S |
Comprehensive Error | 0.03 | Input Resistance | 395±10Ω |
Output Sensitivity | 2.0±0.2mV/V | Output Resistance | 350±10Ω |
Non-linearity | ±0.02%F.S | Insulation Resistance | ≥3000MΩ (50V) |
Repeatability | ±0.02%F.S | Excitation Voltage | ≤10V |
Hysteresis | ±0.02%F.S | Operation Temp.Range | -10--+40℃ |
Creep | ±0.03(5min)%F.S | Overload Capacity | 150%F.S |
Temp.Effect on Zero | ±0.05%F.S/10℃ | Recommended Use | For waterproof scales |
China Manufacture Aluminum Single Point Miniature Sensors
Technical Parameter:
Model | AM007 | Temp.Effect on Output | ±0.02%F.S/10℃ |
Capacity | 5/15/40kG | Zero Output | ±0.08%F.S |
Comprehensive Error | 0.03 | Input Resistance | 395±10Ω |
Output Sensitivity | 2.0±0.2mV/V | Output Resistance | 350±10Ω |
Non-linearity | ±0.02%F.S | Insulation Resistance | ≥3000MΩ (50V) |
Repeatability | ±0.02%F.S | Excitation Voltage | ≤10V |
Hysteresis | ±0.02%F.S | Operation Temp.Range | -10--+40℃ |
Creep | ±0.03(5min)%F.S | Overload Capacity | 150%F.S |
Temp.Effect on Zero | ±0.05%F.S/10℃ | Recommended Use | For waterproof scales |
