Zhejiang, China
SAINTBOND Axle Weighing System
AS021 Axle Weighing System
110V , 220V or according to customer's requirement
LED or LCD
Axle Weighing System
Aluminum-alloy
Welcome
OEM&ODM
1pcs per type per capacity
25~45 DAYS
OEM & ODM Manufacture
High precision 20t 40 ton Truck scales weight portable axle weighing system
Output Sensitivity: | 1±0.2m V/V | Temp., Compensated: | -10~+50℃ |
Combined Error : | 0.2(%ld | Temp., Operating: | -40~+80℃ |
Non-Linearity: | 0.2%ld | Excitation, Recommended (V): | 9~15DC |
Repeatability: | 0.1%ld | Excitation, Max.(V): | 20DC |
Input Resistance: | 3120±40Ω | Safe Overload: | 120%FS |
Ouput Resistance: | 2800±10Ω | Ultimate Overload: | 150%FS |
Insulation Resistance: | ≥5000(100VDC) | Protection Class: | IP66 |
Zero Balance : | 4~10%FS | Cable Spec.: | 4-wire shield cable |
Tem. Effect On Sensitivity : | 0.1%FS/10℃ | Max. Load For Single Point (t): | 10t |
Temp. Effect On Zero: | 0.1%FS/10℃ | Rated Capacity (t): | 15t |
Connections: | Red Input(+) Black Input(-) Green Output(+) White Output(-) |
Features:
Light in weight, and convenient transportation.
Integral flat plate construction, high frequency in dynamic response, and high precision.
Applied special treatment, offering high protection class that are suitable for all kinds of environments.
Adopted special material in aero-industry, with good anti-over loading ability.
Assembled with rubber handles, avoided destroying of the handles.
Provided with spring tube, protecting the cables from being crushed.
Mounted with connector and protection block, easy for changing of cables.
Completed with dovetail approach, offering tight connection of the approach and the scale.
Easy for loading on/off of the vehicles.
High precision 20t 40 ton Truck scales weight portable axle weighing system
Output Sensitivity: | 1±0.2m V/V | Temp., Compensated: | -10~+50℃ |
Combined Error : | 0.2(%ld | Temp., Operating: | -40~+80℃ |
Non-Linearity: | 0.2%ld | Excitation, Recommended (V): | 9~15DC |
Repeatability: | 0.1%ld | Excitation, Max.(V): | 20DC |
Input Resistance: | 3120±40Ω | Safe Overload: | 120%FS |
Ouput Resistance: | 2800±10Ω | Ultimate Overload: | 150%FS |
Insulation Resistance: | ≥5000(100VDC) | Protection Class: | IP66 |
Zero Balance : | 4~10%FS | Cable Spec.: | 4-wire shield cable |
Tem. Effect On Sensitivity : | 0.1%FS/10℃ | Max. Load For Single Point (t): | 10t |
Temp. Effect On Zero: | 0.1%FS/10℃ | Rated Capacity (t): | 15t |
Connections: | Red Input(+) Black Input(-) Green Output(+) White Output(-) |
Features:
Light in weight, and convenient transportation.
Integral flat plate construction, high frequency in dynamic response, and high precision.
Applied special treatment, offering high protection class that are suitable for all kinds of environments.
Adopted special material in aero-industry, with good anti-over loading ability.
Assembled with rubber handles, avoided destroying of the handles.
Provided with spring tube, protecting the cables from being crushed.
Mounted with connector and protection block, easy for changing of cables.
Completed with dovetail approach, offering tight connection of the approach and the scale.
Easy for loading on/off of the vehicles.
