High Quality 20 Ton Dynamic Axle Scale Aluminum alloy Weighing Weigh Pad


PDF Export

  • Zhejiang, China
  • SAINTBOND Weighing Weigh Pad
  • AS010W(6Pcs) Weighing Weigh Pad
  • 110V , 220V or according to customer's requirement
  • LED or LCD
  • Weighing Weigh Pad
  • Aluminum-alloy
  • Welcome
  • 1pcs per type per capacity
  • 25~45 DAYS
  • OEM & ODM Manufacture

High Quality 20 Ton Dynamic Axle Scale Aluminum alloy Weighing Weigh Pad



Wireless Specification

A/D Conversion Method

Σ-Δ 24bit

Input Signal Range


Load Cell Excitation


Max. Connection Number Of Load Cell


Load Cell Connection Mode

4 wire

Operating Temperature

-10°C~40 °C

Allowable Working Temperature

-40 °C ~70 ° C

Wireless Transmission Frequency

430MHz to 470MHz

Wireless Transmission Distance

800 meters (In Open Place)

Weighing Pad Product Parameters

Rated Load:10/15/20T

Compensated temp.range(℃): -10~+50

Dynamic Error (%F.S): 3 (5~10km/h)

Static error (%F.S):0.1~0.3

Static Comprehensive Error(%F.S): 0.1~0.5

Insulation resistance(MΩ): ≥5000(100VDC)

Rated Output(Mv/V): 1.0±0.1

Use temp.range(℃): -30~+80

Non-Linearity(%F.S): 0.2

Temp.effect on zero(F.S/10℃): 0.03

Error On Corners(%F.S): 0.2

Temp.effect on span(F.S/10℃): 0.05

Repeatariy(%F.S): 0.05

Safe overload(%): 120

Zero Balance(%F.S): ±1

Ultimate overload(%): 150

Excitation Voltage(VDC): 9~15

Net weight(kg): 45

Recommended Voltage(V): 10

Defend grade: IP66

Dynamic Comprehensive Error(%F.S):

1.5 (1~5km/h) 3 (5~10km/h)





Q: Could you offer more information about the products, and quote a best price ?
A: Yes, certainly, we will send our product catalogue and company introduction for your reference.

You can choose one or some model, I will advice suitable one for you, also with best price details.

Q: Are you manufacture or trading company ?
A: We are manufacture, also have own export right under our export company. Welcome to visit our factory, check our quality and service.

Q: How long is your delivery time ? What's your payment terms ?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity. Payment terms is TT, LC, Cash, also can be negotiation with us.

Q: Your price is a little bit higher than my target, can you offer a better price ?
A: Yes, price can be negotiation, we try our best to meet your target, let's find a win-win solution, we always keep long term cooperation relations with customers.
