SAINTBOND High Range Pressure Transmitters
PT02 High Range Pressure Transmitters
mini pressure transducer
Aluminum-alloy
Compatible with 17-4 PH stainless steel of gas and liquid
9~30VDC
Welcome
OEM&ODM
1pcs per type per capacity
20~45 DAYS
OEM & ODM Manufacture
IP65 German import plugs 600Mpa High Range Pressure Transmitters
Dimension:
Technical Data:
Measuring Medium | Compatible with 17-4 PH stainless steel of gas and liquid |
Measuring Range | 0～40…600Mpa |
Pressure References | Gauge |
Proof Pressure | 125%FS |
Burst Pressure | 150%FS |
Power Supply | 9～30VDC |
Output Signal | 4～20ma; 0～5V; 1～5V; 0～10V etc; |
Accuracy | ±0.5%FS; ±0.25%FS; ±0.1%FS optional |
Temperature Coefficient Of Zero | ±0.2%FS/10℃ |
Temperature Coefficient Of Span | ±0.2%FS/10℃ |
Compensated Temperature Range | 0～70℃; -20～85℃ (Optional) |
Operating Temperature Range | -40～85℃; -40～120℃ (Optional) |
Insulation Resistance | ≥500MΩ |
Load Resistance For Current Loop | ≥[(vs-6.5V)/0.02A]Ω |
Mechanical Interface | M20×1.5; G1/4"; special thread can be customized |
Electrical Interface | DIN,DIN with digital display,aviation plug,spring direct,polyurethane sheath, 2088 etc optional |
Life Time | ≥5million times cycles |
Long-Term Stability | ≤±0.15%FS/year |
Conventional pressure transmitter connection mode
Type | 4~20mA | 0-5V / 0~10V | |
Two-Wire | Three-Wire | Four-Wire | |
Spring Direc | Red:Power+ Black:Signal+ | Red:Power+; Black:Ground Green:Signal+ |
|
Aviation Plug DIN43650 | Red (1):Power+ Black (2):Signal+ | Red (1):Power+; Black (2):Ground Green (3):Signal+ |
|
Gray Aviation Plug | Black (1):Signal+ Red (4):Power+ | Black (1):Signal+; Green (3):Ground Red (4):Power+ | Black (1):Signal+ White(2):-12V Green (3):Ground Red (4):+12V |
This form is for reference only, please refer to our product factory test report
Features:
Measuring diaphragm and pressure interface one-piece structure;
Thread interface USES 7 degrees of taper sealing surface;
Resistance to vibration the instantaneous pressure impact resistance;
Can measure pressure up to 600 MPa;
With German import plugs IP65 standard seal.
IP65 German import plugs 600Mpa High Range Pressure Transmitters
Dimension:
Technical Data:
Measuring Medium | Compatible with 17-4 PH stainless steel of gas and liquid |
Measuring Range | 0～40…600Mpa |
Pressure References | Gauge |
Proof Pressure | 125%FS |
Burst Pressure | 150%FS |
Power Supply | 9～30VDC |
Output Signal | 4～20ma; 0～5V; 1～5V; 0～10V etc; |
Accuracy | ±0.5%FS; ±0.25%FS; ±0.1%FS optional |
Temperature Coefficient Of Zero | ±0.2%FS/10℃ |
Temperature Coefficient Of Span | ±0.2%FS/10℃ |
Compensated Temperature Range | 0～70℃; -20～85℃ (Optional) |
Operating Temperature Range | -40～85℃; -40～120℃ (Optional) |
Insulation Resistance | ≥500MΩ |
Load Resistance For Current Loop | ≥[(vs-6.5V)/0.02A]Ω |
Mechanical Interface | M20×1.5; G1/4"; special thread can be customized |
Electrical Interface | DIN,DIN with digital display,aviation plug,spring direct,polyurethane sheath, 2088 etc optional |
Life Time | ≥5million times cycles |
Long-Term Stability | ≤±0.15%FS/year |
Conventional pressure transmitter connection mode
Type | 4~20mA | 0-5V / 0~10V | |
Two-Wire | Three-Wire | Four-Wire | |
Spring Direc | Red:Power+ Black:Signal+ | Red:Power+; Black:Ground Green:Signal+ |
|
Aviation Plug DIN43650 | Red (1):Power+ Black (2):Signal+ | Red (1):Power+; Black (2):Ground Green (3):Signal+ |
|
Gray Aviation Plug | Black (1):Signal+ Red (4):Power+ | Black (1):Signal+; Green (3):Ground Red (4):Power+ | Black (1):Signal+ White(2):-12V Green (3):Ground Red (4):+12V |
This form is for reference only, please refer to our product factory test report
Features:
Measuring diaphragm and pressure interface one-piece structure;
Thread interface USES 7 degrees of taper sealing surface;
Resistance to vibration the instantaneous pressure impact resistance;
Can measure pressure up to 600 MPa;
With German import plugs IP65 standard seal.
