SAINTBOND Single Ended Shear Beam Load Cells
LC303 Single Ended Shear Beam Load Cells
Weighing
Resistance Sensor
Other
Single Ended Shear Beam Load Cells
0.5t/10t
A:Alloy Steel, SS:Stainless Steel
15V DC
10~12V DC
IP67/IP68
Welcome
OEM&ODM
1pcs per type per capacity
OEM & ODM Manufacture
IP67 IP68 Stainless Steel Single Ended Shear Beam Load Cells
Cap./Size | A | B | C | D | E | F | H | G | M | X |
100~2500 kg | 130 | 32 | 32 | 13 | 15 | 25.4 | 15 | 75 | M12×1.25 | 55 |
3000~5000 kg | 172 | 38 | 38 | 21 | 19 | 38.1 | 19 | 95 | M20×1.50 | 76 |
7500~10000 kg | 223 | 50 | 50 | 25 | 25 | 50.8 | 25 | 120 | M24×2.00 | 100 |
Technical Parameter:
Rated Load: | 0.1/0.15/0.2/0.25/0.3/0.5/0.75/1.5/2.5/3/5/7.5/10t | ||
Sensitivity: | (2.0±0.1%) m V/V, (3.0±0.1%) m V/V | Operating Temp. Range: | -30~+70℃ |
Combined Error: | ±0.02% F.S | Max. Safe Over Load: | 150%F.S |
Creep Error(30min): | ±0.02% F.S | Ultimate Over Load: | 250%F.S |
Zero Balance: | ±1% F.S | Recommend Excitation: | 10~12V DC |
Temp. Effect On Zero: | ±0.02% F.S/10℃ | Maximum Excitation: | 15V DC |
Temp. Effect On Span: | ±0.02% F.S/10℃ | Sealing Class: | IP67/IP68 |
Input Resistance: | 385±5Ω | Element Material: | A:Alloy Steel, SS:Stainless Steel |
Output Resistance: | 352±2Ω | Cable: | Length=L:3m |
Insulation Resistance: | ≥5000MΩ | Citation: | GB/T7551-2008/ OIML R60 |
Mode Of Connection: | Red(Input+),Black(Input-),Green(Output+),White(Output-) |
Products Specification:
LC303 load cells are available in the capacities 0.5t to 10t.
Alloy steel,sealed by adhesive inside,oil-proof,waterproof and anti-corrosion, suitable for all kinds of environment.
Single shear beam, easy for installation,suitable for electronic platform scales,hopper scales and other electronic weighing devices.
Safe and anti-explosive product,can be used in atrocious environment and hazardous areas.
IP67 IP68 Stainless Steel Single Ended Shear Beam Load Cells
Cap./Size | A | B | C | D | E | F | H | G | M | X |
100~2500 kg | 130 | 32 | 32 | 13 | 15 | 25.4 | 15 | 75 | M12×1.25 | 55 |
3000~5000 kg | 172 | 38 | 38 | 21 | 19 | 38.1 | 19 | 95 | M20×1.50 | 76 |
7500~10000 kg | 223 | 50 | 50 | 25 | 25 | 50.8 | 25 | 120 | M24×2.00 | 100 |
Technical Parameter:
Rated Load: | 0.1/0.15/0.2/0.25/0.3/0.5/0.75/1.5/2.5/3/5/7.5/10t | ||
Sensitivity: | (2.0±0.1%) m V/V, (3.0±0.1%) m V/V | Operating Temp. Range: | -30~+70℃ |
Combined Error: | ±0.02% F.S | Max. Safe Over Load: | 150%F.S |
Creep Error(30min): | ±0.02% F.S | Ultimate Over Load: | 250%F.S |
Zero Balance: | ±1% F.S | Recommend Excitation: | 10~12V DC |
Temp. Effect On Zero: | ±0.02% F.S/10℃ | Maximum Excitation: | 15V DC |
Temp. Effect On Span: | ±0.02% F.S/10℃ | Sealing Class: | IP67/IP68 |
Input Resistance: | 385±5Ω | Element Material: | A:Alloy Steel, SS:Stainless Steel |
Output Resistance: | 352±2Ω | Cable: | Length=L:3m |
Insulation Resistance: | ≥5000MΩ | Citation: | GB/T7551-2008/ OIML R60 |
Mode Of Connection: | Red(Input+),Black(Input-),Green(Output+),White(Output-) |
Products Specification:
LC303 load cells are available in the capacities 0.5t to 10t.
Alloy steel,sealed by adhesive inside,oil-proof,waterproof and anti-corrosion, suitable for all kinds of environment.
Single shear beam, easy for installation,suitable for electronic platform scales,hopper scales and other electronic weighing devices.
Safe and anti-explosive product,can be used in atrocious environment and hazardous areas.
