Zhejiang, China
SAINTBOND Tensile Load Link sensor
LC220CW Tensile Load Link sensor
Weighing
Other
Other
Tensile Load Link sensor
1/2/5/12/25/35/50/75/100/150/200/250/300/500T
2 Pcs
OEM&ODM
45 -50DAYS
15~30Days
15 years experience on Load Cell
IP67 Small crane weight tension load cell Tensile Load Link sensor
Cap./t | H | W | L | L1 | A |
1~5t | 76 | 34 | 230 | 160 | 38 |
7.5~10t | 90 | 47 | 280 | 180 | 40 |
20~30t | 125 | 55 | 370 | 230 | 53 |
40~60t | 150 | 85 | 430 | 254 | 73 |
80~150t | 220 | 115 | 580 | 340 | 98 |
200t | 265 | 183 | 725 | 390 | 280 |
250t | 300 | 200 | 800 | 425 | 305 |
300t | 345 | 200 | 875 | 460 | 305 |
500t | 570 | 200 | 930 | 510 | 30 |
Wireless Load Links Typical Specifications:
Rate Load: | 1/5/10/20/30/50/80/100/150/200/250/300/500T | ||
Battery Type: | 18650 rechargeable batteries or polymer batteries (7.4v 2000 Mah) | ||
Proof Load: | 150% of rate load | Max. Safety Load: | 125% F.S. |
Ultimate Load: | 400% F.S. | Battery Life: | ≥40 hours |
Power On Zero Range: | 20% F.S. | Operating Temp.: | - 10℃ ~ + 40℃ |
Manual Zero Range: | 4% F.S. | Stable Time: | ≤10seconds; |
Tare Range: | 20% F.S. | Remote Controller Distance: | Min.15m |
Operating Humidity: | ≤85% RH under 20℃ | System Range: | 500~800m (In Open Area) |
IP67 Small crane weight tension load cell Tensile Load Link sensor
Cap./t | H | W | L | L1 | A |
1~5t | 76 | 34 | 230 | 160 | 38 |
7.5~10t | 90 | 47 | 280 | 180 | 40 |
20~30t | 125 | 55 | 370 | 230 | 53 |
40~60t | 150 | 85 | 430 | 254 | 73 |
80~150t | 220 | 115 | 580 | 340 | 98 |
200t | 265 | 183 | 725 | 390 | 280 |
250t | 300 | 200 | 800 | 425 | 305 |
300t | 345 | 200 | 875 | 460 | 305 |
500t | 570 | 200 | 930 | 510 | 30 |
Wireless Load Links Typical Specifications:
Rate Load: | 1/5/10/20/30/50/80/100/150/200/250/300/500T | ||
Battery Type: | 18650 rechargeable batteries or polymer batteries (7.4v 2000 Mah) | ||
Proof Load: | 150% of rate load | Max. Safety Load: | 125% F.S. |
Ultimate Load: | 400% F.S. | Battery Life: | ≥40 hours |
Power On Zero Range: | 20% F.S. | Operating Temp.: | - 10℃ ~ + 40℃ |
Manual Zero Range: | 4% F.S. | Stable Time: | ≤10seconds; |
Tare Range: | 20% F.S. | Remote Controller Distance: | Min.15m |
Operating Humidity: | ≤85% RH under 20℃ | System Range: | 500~800m (In Open Area) |
