Zhejiang, China
SAINTBOND
MiNi025
Weigh the weight of the weigher
Convert electrical signal to the force signal
Analog Sensor
LX-WX7 Mini Compression Load Cell
Stainless Steel / Alloy Steel
1SET
1.0~2.0mV/V
50~5000kg
truck scale, electronic scale and other weighing devices
-10-+40℃
10~12V DC
≤±0.1 mV/V
Alloy steel or stainless steel
Miniature Type Force Sensor Compression Mini Micro Button Load Cell
Dimension:
Description:
It has the characteristics of high precision, high dynamic response, small size and easy installation. It is suitable for riveting machine, extrusion equipment, film press, impact testing and industrial automation measurement and control fields.
Rated Capacity | 5~1000kg | Excitation,Recommended | 5~12VDC(10VDC) |
Sensitivity | 1.0~2.0mV/V | Operating Temp.Range | -10-+40℃ |
Zero Balance | ≤±0.1 mV/V | Safe Overload | 120%R.C. |
Rated Output | 2.0±0.5%mV/V | Insulation Resistance | ≥2000MΩ(50VDC) |
Input Resistance | 380±30Ω/730±30Ω | Hysteresis Error | ±0.05%R.O. |
Output Resistance | 350±2Ω/700±2Ω | Creep in 2 Min. | ±0.05%R.O. |
Linearlty Error | ±0.05%R.O. | Temp.Effect on Output | ±0.05%R.O./10℃ |
Repeatability Error | ±0.05%R.O. | Temp.Effect on Zero | ±0.05%R.O./10℃ |
FAQ:
Q: Could you offer more information about the products, and quote a best price ?
A: Yes, certainly, we will send our product catalogue and company introduction for your reference.
You can choose one or some model, I will advice suitable one for you, also with best price details.
Q: Are you manufacture or trading company ?
A: We are manufacture, also have own export right under our export company. Welcome to visit our factory, check our quality and service.
Q: How long is your delivery time ? What's your payment terms ?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity. Payment terms is TT, LC, Cash, also can be negotiation with us.
Q: Your price is a little bit higher than my target, can you offer a better price ?
A: Yes, price can be negotiation, we try our best to meet your target, let's find a win-win solution, we always keep long term cooperation relations with customers.
Miniature Type Force Sensor Compression Mini Micro Button Load Cell
Dimension:
Description:
It has the characteristics of high precision, high dynamic response, small size and easy installation. It is suitable for riveting machine, extrusion equipment, film press, impact testing and industrial automation measurement and control fields.
Rated Capacity | 5~1000kg | Excitation,Recommended | 5~12VDC(10VDC) |
Sensitivity | 1.0~2.0mV/V | Operating Temp.Range | -10-+40℃ |
Zero Balance | ≤±0.1 mV/V | Safe Overload | 120%R.C. |
Rated Output | 2.0±0.5%mV/V | Insulation Resistance | ≥2000MΩ(50VDC) |
Input Resistance | 380±30Ω/730±30Ω | Hysteresis Error | ±0.05%R.O. |
Output Resistance | 350±2Ω/700±2Ω | Creep in 2 Min. | ±0.05%R.O. |
Linearlty Error | ±0.05%R.O. | Temp.Effect on Output | ±0.05%R.O./10℃ |
Repeatability Error | ±0.05%R.O. | Temp.Effect on Zero | ±0.05%R.O./10℃ |
