Zhejiang, China
SAINTBOND
MX011
Weigh the weight of the weigher
Convert electrical signal to the force signal
0.5~10MV
multiaxial 3 axis load cell multi axis ati force sensor
Alloy Steel / Stainless steel
Welcome
Factory supply
Good quality and low price
0.35X0.3X0.2cm
5~40Days
The price according to capacity
All over the world
OEM/ODM
multiaxial 3 axis load cell multi axis ati force sensor
Cap.(kN/N.m) | A | B |
10/300,20/500, 30/700 | 25 | 23 |
50/1000 | 30 | 28 |
Rated Load(N/N.m): | F: 10/20/30/50kN | ||
Rated output: | 1.0±10%mV/V | Output impedance: | 700±10Ω |
Zero balance: | ±2%F.S. | Insulation: | ≥5000MΩ/100VDC |
Non-linearity: | 0.1%F.S. | Recommended excitation: | 5~15V |
Hysteresis: | 0.1%F.S. | Maximum excitation: | 20V |
Repeatability: | 0.1%F.S. | Compensated temp range: | -10~40℃ |
Creep(30min): | 0.2%F.S. | Operation temp range: | -20~75℃ |
Temp.effect on output: | 0.05%F.S. | Safe overload: | 150%F.S. |
Temp.effect on zero: | 0.05%F.S./10℃ | Ultimate overload: | 200%F.S. |
Input impedance: | 780±20Ω | Weight approx. | 0.6kg |
FAQ:
Q: Could you offer more information about the products, and quote a best price ?
A: Yes, certainly, we will send our product catalogue and company introduction for your reference.
You can choose one or some model, I will advice suitable one for you, also with best price details.
Q: Are you manufacture or trading company ?
A: We are manufacture, also have own export right under our export company. Welcome to visit our factory, check our quality and service.
Q: How long is your delivery time ? What's your payment terms ?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity. Payment terms is TT, LC, Cash, also can be negotiation with us.
Q: Your price is a little bit higher than my target, can you offer a better price ?
A: Yes, price can be negotiation, we try our best to meet your target, let's find a win-win solution, we always keep long term cooperation relations with customers.
multiaxial 3 axis load cell multi axis ati force sensor
Cap.(kN/N.m) | A | B |
10/300,20/500, 30/700 | 25 | 23 |
50/1000 | 30 | 28 |
Rated Load(N/N.m): | F: 10/20/30/50kN | ||
Rated output: | 1.0±10%mV/V | Output impedance: | 700±10Ω |
Zero balance: | ±2%F.S. | Insulation: | ≥5000MΩ/100VDC |
Non-linearity: | 0.1%F.S. | Recommended excitation: | 5~15V |
Hysteresis: | 0.1%F.S. | Maximum excitation: | 20V |
Repeatability: | 0.1%F.S. | Compensated temp range: | -10~40℃ |
Creep(30min): | 0.2%F.S. | Operation temp range: | -20~75℃ |
Temp.effect on output: | 0.05%F.S. | Safe overload: | 150%F.S. |
Temp.effect on zero: | 0.05%F.S./10℃ | Ultimate overload: | 200%F.S. |
Input impedance: | 780±20Ω | Weight approx. | 0.6kg |
