Zhejiang, China
SAINTBOND Wireless High Temperature Proof Crane Scale
CS-DHA Wireless High Temperature Proof Crane Scale
CRANE SCALE
110V , 220V or according to customer's requirement
LED LCD
15t
0.1kg
Wireless High Temperature Proof Crane Scale
Welcome
OEM&ODM
1pcs per type per capacity
10~25 DAYS
OEM & ODM Manufacture
Weighing Scale
Professional Manufacture 1t/2t/3t/5t/10/15t Wireless High Temperature Proof Crane Scale
Pecification:
Model | Max Cap | Min. Weigh | Division | Total Display Counts |
| (Kg) | (Kg) | (Kg) | (N) |
CS-DHA-1 | 1000 | 10 | 0.5 | 2000 |
CS-DHA-2 | 2000 | 20 | 0.5 | 2000 |
CS-DHA-3 | 3000 | 20 | 1 | 3000 |
CS-DHA-5 | 5000 | 40 | 1 | 2500 |
CS-DHA-10 | 10000 | 100 | 2 | 2000 |
CS-DHA-15 | 15000 | 100 | 2 | 2000 |
Min Distance Between Scale And High Temperature:
1000℃ | 1200℃ | 1400℃ | 1600℃ |
1.2m | 1.5m | 1.8m | 2.0mCapacity: 1t/2t/3t/5t/10/15t |
Capacity: 1t/2t/3t/5t/10/15t
Ultra- low-power design, circuit board smaller.
Large capacity battery configuration, longer life.
Unique intelligent charging protection function, prevention of over- current, over charge phenomenon. The battery life of a stronger, more
Lasting.
Ultra-bright, low-brightness display, automatic adjustment ( to be set )
Startup, shutdown, automatic voltage display.
Good dynamic weighing performance, not because of swaying affect the weighing
With a wireless remote control for easy operation.
Cumulative,automatic total, peeled, peeled distance, numerical maintained, showing sub- value choice, any weight correction.
Overload, underload remind display, low voltage alarm, battery capacity is less than 10 % of the police.Technical Specifications
Specially designed for metallurgy ,like iron and steel plant.
Optional wireless communication module, the working carrier frequency is 430MHz ~ 470MHz
ISM band between the open, license-free use,
The current weighing data to within 800m wireless meter or PC display or management.
Accuracy class according to international standard three scales.
Battery charging time of about 70 hours working time
Safe overload 150% F.S
Destruction of overloading 300% F.S
Operating temperature -10 ~ 50 ℃
Environment Humidity<90% R.H
Monitor specifications 5 30mm (1.2)LED high brightness displays.
Reading stabilization time<3S
Remote distance<25M
Professional Manufacture 1t/2t/3t/5t/10/15t Wireless High Temperature Proof Crane Scale
Pecification:
Model | Max Cap | Min. Weigh | Division | Total Display Counts |
| (Kg) | (Kg) | (Kg) | (N) |
CS-DHA-1 | 1000 | 10 | 0.5 | 2000 |
CS-DHA-2 | 2000 | 20 | 0.5 | 2000 |
CS-DHA-3 | 3000 | 20 | 1 | 3000 |
CS-DHA-5 | 5000 | 40 | 1 | 2500 |
CS-DHA-10 | 10000 | 100 | 2 | 2000 |
CS-DHA-15 | 15000 | 100 | 2 | 2000 |
Min Distance Between Scale And High Temperature:
1000℃ | 1200℃ | 1400℃ | 1600℃ |
1.2m | 1.5m | 1.8m | 2.0mCapacity: 1t/2t/3t/5t/10/15t |
Capacity: 1t/2t/3t/5t/10/15t
Ultra- low-power design, circuit board smaller.
Large capacity battery configuration, longer life.
Unique intelligent charging protection function, prevention of over- current, over charge phenomenon. The battery life of a stronger, more
Lasting.
Ultra-bright, low-brightness display, automatic adjustment ( to be set )
Startup, shutdown, automatic voltage display.
Good dynamic weighing performance, not because of swaying affect the weighing
With a wireless remote control for easy operation.
Cumulative,automatic total, peeled, peeled distance, numerical maintained, showing sub- value choice, any weight correction.
Overload, underload remind display, low voltage alarm, battery capacity is less than 10 % of the police.Technical Specifications
Specially designed for metallurgy ,like iron and steel plant.
Optional wireless communication module, the working carrier frequency is 430MHz ~ 470MHz
ISM band between the open, license-free use,
The current weighing data to within 800m wireless meter or PC display or management.
Accuracy class according to international standard three scales.
Battery charging time of about 70 hours working time
Safe overload 150% F.S
Destruction of overloading 300% F.S
Operating temperature -10 ~ 50 ℃
Environment Humidity<90% R.H
Monitor specifications 5 30mm (1.2)LED high brightness displays.
Reading stabilization time<3S
Remote distance<25M
