Small Digital Vehicle Weighing Pads







(mm)



(Double Pads for One Axel)

AS002

350×350×35

1000/2000/3000Kg

4pcs LC348 LoadCell,10m Cable

Capacity:500/1000/1500Kg

400×500×56.5

3000/5000/6000/10000Kg

4pcs LC348 LoadCell,10m Cable

Capacity:1500/2500/3000/5000Kg

450×700×56.5

10000/20000/30000Kg

4pcs LC348 LoadCell,10m Cable

Capacity:5000/10000/15000Kg

500×900×56.5

20000/30000/40000Kg

4pcs LC348 LoadCell,10m Cable

Rated load:1/2/3/5/6/10/20/30/40T

Compensated temp.range(℃): -10~+50

Dynamic error (%F.S): 3 (5~10km/h)

Static error (%F.S):0.1~0.3

Static comprehensive error(%F.S): 0.1~0.5

Insulation resistance(MΩ): ≥5000(100VDC)

Rated output(mV/V): 1.0±0.1

Use temp.range(℃): -30~+80

Non-linearity(%F.S): 0.2

Temp.effect on zero(F.S/10℃): 0.03

Error on corners(%F.S): 0.2

Temp.effect on span(F.S/10℃): 0.05

Repeatariy(%F.S): 0.05

Safe overload(%): 120

Zero balance(%F.S): ±1

Ultimate overload(%): 150

Excitation voltage(VDC): 9~15

Net weight(kg): 45

Recommended voltage(V): 10

Defend grade: IP66

A/D conversion method

Σ-Δ 24bit

Input signal range

–19.5mV~19.5mV

Load cell excitation

DC 5V

Max. connection number of load cell

1~4

Load cell connection mode

4 wire

Operating temperature

-10 °C ~40 °C

Allowable working temperature

-40 ° C ~ 70 ° C

Wireless transmission frequency

430MHz to 470MHz

Wireless transmission distance

800 meters (In Open Place)
