Zhejiang, China
SAINTBOND
Model380
Weigh the weight of the weigher
Convert electrical signal to the force signal
2.0mV/V
Tedea-Huntleigh 380 Aluminum Point Planar Beam Single Load Cells
Aluminum
1SET
Good quality and low price
OEM&ODM
Welcome
5~40Days
30% advance payment, the rest payment before delivery
Carton,0.35x0.3x0.2cm
Tedea-Huntleigh 380 Aluminum Point Planar Beam Single Load Cells
Model 380 is a very low profile planar beam design, allowing direct mounting in low profile platform scales. The range of capacities and low profile makes model 380 most suitable for use in a wide range of applications.
Capacity | A | B | C | D | E | F | G | H | I |
7.5kg | 70 | 39 | 2.5 | 28 | 14 | 4.9 | 27.8 | 5.1 | 5.1 |
37.5kg | 76.2 | 44.5 | 4.8 | 29.3 | 15 | 6 | 30 | 6.6 | 6.2 |
50kg | 84.5 | 55 | 5.3 | 34 | 15 | 6.4 | 30 | 6.6 | 7.6 |
75kg | 84.5 | 55 | 6.4 | 34 | 15 | 6.4 | 30 | 6.6 | 7.6 |
150kg | 107.5 | 70 | 8 | 45.9 | 22.8 | 7.8 | 44.5 | 8.1 | 8.2 |
Rated Capacity: | 7.5/37.5/50/7/150kg | Insulation Resistance: | >5000M |
Full Scale Output: | 1.0mV/V ± 0.1% | Temp. Effect on Sensitivity: | <±0.0015% of Cn/k |
Zero Balance: | ± 0.02mV/V | Temp.Effect on Zero Balance: | <± 0.0030% of Cn/k |
Non-linearity: | < ± 0.020% | Nominal Temperature Range: | –10°C to 40°C/14°F to 104°F |
Repeatability: | < ± 0.017% | Service Temperature Range: | –18°C to 65°C/0°F to 149°F |
Hysteresis Error: | < ± 0.015% | Storage Temperature Range: | -50°C to 85°C/-58°F to 185°F |
Creep in 30 minutes: | < ± 0.015% | Safe Overload: | 150% of full scale |
Input Resistance: | 1160Ω ± 10Ω | Breaking Overload: | 300% of full scale |
Output Resistance: | 1000Ω ± 10Ω | Safe side bad: | 200% of full scale |
Recommended Excitation: | 10V (15V Maximum) | Construction: | Aluminum |
Cable length: | 1.5m | IP Rating: | IP65 |
Tedea-Huntleigh 380 Aluminum Point Planar Beam Single Load Cells
Model 380 is a very low profile planar beam design, allowing direct mounting in low profile platform scales. The range of capacities and low profile makes model 380 most suitable for use in a wide range of applications.
Capacity | A | B | C | D | E | F | G | H | I |
7.5kg | 70 | 39 | 2.5 | 28 | 14 | 4.9 | 27.8 | 5.1 | 5.1 |
37.5kg | 76.2 | 44.5 | 4.8 | 29.3 | 15 | 6 | 30 | 6.6 | 6.2 |
50kg | 84.5 | 55 | 5.3 | 34 | 15 | 6.4 | 30 | 6.6 | 7.6 |
75kg | 84.5 | 55 | 6.4 | 34 | 15 | 6.4 | 30 | 6.6 | 7.6 |
150kg | 107.5 | 70 | 8 | 45.9 | 22.8 | 7.8 | 44.5 | 8.1 | 8.2 |
Rated Capacity: | 7.5/37.5/50/7/150kg | Insulation Resistance: | >5000M |
Full Scale Output: | 1.0mV/V ± 0.1% | Temp. Effect on Sensitivity: | <±0.0015% of Cn/k |
Zero Balance: | ± 0.02mV/V | Temp.Effect on Zero Balance: | <± 0.0030% of Cn/k |
Non-linearity: | < ± 0.020% | Nominal Temperature Range: | –10°C to 40°C/14°F to 104°F |
Repeatability: | < ± 0.017% | Service Temperature Range: | –18°C to 65°C/0°F to 149°F |
Hysteresis Error: | < ± 0.015% | Storage Temperature Range: | -50°C to 85°C/-58°F to 185°F |
Creep in 30 minutes: | < ± 0.015% | Safe Overload: | 150% of full scale |
Input Resistance: | 1160Ω ± 10Ω | Breaking Overload: | 300% of full scale |
Output Resistance: | 1000Ω ± 10Ω | Safe side bad: | 200% of full scale |
Recommended Excitation: | 10V (15V Maximum) | Construction: | Aluminum |
Cable length: | 1.5m | IP Rating: | IP65 |
