SAINTBOND torque transducer
T7 torque transducer
The electrical signal of the elastic axis is measured
Resistance Sensor
2.0mV/V or 3.0mV/V or according to customer's requirement
torque transducer
Alloy Steel, Stainless Steel
Welcome
OEM&ODM
1pcs per type per capacity
25~45 DAYS
OEM & ODM Manufacture
The best Small Light Force Torque Sensor 5NM Alloy Stainless Steel torque transducer
Measuring Range | 0±5NM | Use Temperature | -1 0~5 0 ℃ |
Torque Precision | ± 0. 5 % F·S ± 0. 3 % F·S(Optional) | Signal | Torque signal Speed Signal |
Response Frequency | 100 μ s | Storage Temperature | -20~70 ℃ |
Nonlinear | ± 0. 3 % F · S | Supply Voltage | ± 15V ± 5 % |
Zero Temperature Drift | ± 0. 3 % F · S | Load Current | <10mA |
Insulation Resistance | >500M Ω | Relative Humidity | ≤95%RH |
Static Overload | 150% | Suitable Speed | 10000RPM/Min |
Features:
T7 series torque sensor is a typical structure of non-contact torque sensor, the output signal of non contact mode, the high frequency part of the signal is filtered by the detection circuit, only the torque signal is amplified. Non contact torque sensor due to the use of the non contact work, and long service life, high reliability, less susceptible to wear, less delay, deflection and axial offset axis impact smaller, now has been widely used in cars and light vehicles, is the mainstream product of EPS sensor.
The internal use of unique non-contact mode wireless transmission torque signal output.
With good stability, high precision, good reliability and long life.
Can measure dynamic torque, static torque; measurement of torque signal output and speed of high or low.
Whether it has nothing to do with rotation or steering.
Do not need to repeatedly adjust the zero position to continuously measure the positive and negative torque signal.
Signal using digital technology, strong anti-interference.
No slip ring wear parts, high speed can run for a long time
The measuring precision of torque is independent of the rotation speed and direction.
Positive and negative torque, speed and power can be measured.
Small size, light weight, easy to install, can be any location, any direction of installation.
The best Small Light Force Torque Sensor 5NM Alloy Stainless Steel torque transducer
Measuring Range | 0±5NM | Use Temperature | -1 0~5 0 ℃ |
Torque Precision | ± 0. 5 % F·S ± 0. 3 % F·S(Optional) | Signal | Torque signal Speed Signal |
Response Frequency | 100 μ s | Storage Temperature | -20~70 ℃ |
Nonlinear | ± 0. 3 % F · S | Supply Voltage | ± 15V ± 5 % |
Zero Temperature Drift | ± 0. 3 % F · S | Load Current | <10mA |
Insulation Resistance | >500M Ω | Relative Humidity | ≤95%RH |
Static Overload | 150% | Suitable Speed | 10000RPM/Min |
Features:
T7 series torque sensor is a typical structure of non-contact torque sensor, the output signal of non contact mode, the high frequency part of the signal is filtered by the detection circuit, only the torque signal is amplified. Non contact torque sensor due to the use of the non contact work, and long service life, high reliability, less susceptible to wear, less delay, deflection and axial offset axis impact smaller, now has been widely used in cars and light vehicles, is the mainstream product of EPS sensor.
The internal use of unique non-contact mode wireless transmission torque signal output.
With good stability, high precision, good reliability and long life.
Can measure dynamic torque, static torque; measurement of torque signal output and speed of high or low.
Whether it has nothing to do with rotation or steering.
Do not need to repeatedly adjust the zero position to continuously measure the positive and negative torque signal.
Signal using digital technology, strong anti-interference.
No slip ring wear parts, high speed can run for a long time
The measuring precision of torque is independent of the rotation speed and direction.
Positive and negative torque, speed and power can be measured.
Small size, light weight, easy to install, can be any location, any direction of installation.
