Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Energy & Mining, Food & Beverage Shops, Advertising Company, Construction works , Warehouse
New
Zhejiang, China
SAINTBOND
AC Motor
3380
180mm
3380*1150*2000
CE/ISO9001
1 Year
Online support
New Product 2020
other
Forklift
Good quality and low price
Welcome
OEM&ODM
5~40Days
30% advance payment, the rest payment before delivery
Carton
Description:
we can offer you customized service, the following items are optional: Container mast, for example, 2-stage full free mast of 3m, 3-stage full free mast of 4.5m/ 4.8m side shifter, fork positioner, longer forks, fork extension and all kinds of forklift attachment. For the details of customized configurations and options, please contact with us.
Standard Configuration
Hydraulic Automatic Transmission.
Shimadzu's Pump Valve, Eaton Pipe and NOK Hydraulic Cyr Seals.
Electric-hydraulic Directional Control Valve.
The Casting-type Steering Axle which more than 8 years of service life than ordinary Welded Axle.
The Maintenance Free Radiators adopt Germany Technology.
Adopt Priority Steering System, which improve the work efficiency.
Original Toyota Comfortable Seat with Armrest and Safe-belt, LED Light ect.
Thicker reinforcing overhead guard protective device, ensure the safety.
Middle muffler, more environmental.
Technical Parameter:
Type | CPD1030 | CPD1530 | CPD2030 | CPD3030 |
Capacity(kg) | 1000 | 1500 | 2000 | 3000 |
Lift Height(mm) | 3000 | 3000 | 3000 | 3000 |
Fork Length(mm) | 500 | 500 | 500 | 500 |
Min Ground Height(mm) | 1070 | 1070 | 1070 | 1070 |
Manipulation | Steering Wheel | |||
Tire | Solid Core Tire | |||
Drive wheel dimensions | 510mm | 510mm | 560mm | 650mm |
Full Load Travel Speed | 15km /h | 15km /h | 15km /h | 15km /h |
Full Load Lifting Speed | 200mm/Min. | 200mm/Min. | 200mm/Min. | 200mm/Min. |
Type of driver | Stepless speed regulation | |||
Door Frame Angle | 3-6 | 3-6 | 3-6 | 3-6 |
Full Load Climbing | 15 | 15 | 15 | 15 |
Battery (Vol./Cap.) (V /Ah) | 48/240 | 48/270 | 48/270 | 48/420 |
Reference Usage Time(h) | 3 | 3 | 3.5 | 6 |
Driving Motor(kw) | 4 | 4.2 | 5 | 8 |
Lifting Motor(kw) | 3 | 3 | 5.5 | 5.5 |
Mini. outside Turning Radius | 2000mm | 2000mm | 2100mm | 2150mm |
Dimension L×W×H(mm) | 3380×1050×2100 | 3380×1050×2100 | 3450×1100×2100 | 3600×1160×2120 |
Net Weight(kg) | 2200 | 2000 | 2100 | 2150 |
Lifting Height of Each Cap. Corresponding Height of Gantry | 1600/2000/2500/3000/3500mm 2080/1600/1850/2080/2350mm | |||
CPD Electric Forklift Large Wheel Forklift Full Electric Pallet with Electric Forklift Truck Price
| Product Name | CPD Electric Forklift Large Wheel Forklift Full Electric Pallet with Electric Forklift Truck Price |
| Features | Good quality and low price |
| Service | OEM&ODM |
| Custom Design | Welcome |
| Sample Lead Time | 5~40Days |
| Payment Terms | 30% advance payment, the rest payment before delivery |
| Market | all over the world |
| Form of sale | Factory supply |
Q1:How do you control the quality?
A:We have QC team comply with TQM,each step is in compliance to the standards.At the same time,they
will take photos and shoot video for you.
Q2:Why should I choose your company?
A:1,We have own logistics who cooperate different forwarders at the ports of destination.It's good for you
to do DDP or DDU.
A2:We have own warehouse at the ningbo port China.
If you want to mix disparate products to different stores,we can help you to finish the work when our
workers receive the goods from suppliers. New carton labels will be printed and new pallets with unique
IDs will be created.It will save labor cost for you.
Q3: Can you print our brand on the product?
A: Yes, Of course. It can make customer’s brand logo.
Q4: What is your terms of packing?
A: Generally, we pack our goods in neutral cartons. If you have legally registered patent, we can pack the
goods by your logo after getting your authorization letters.
Q5: What about the Wheel axle scales price?
A: We promise the Wheel axle scales price we offer is lowest if same application, only to enlarge the
market share.
Q6:What’s your company payment terms?
A:L/C at sight/ 30days, T/T 30%deposit 70% before shipment.
Q7:Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery. We have QC team comply with TQM,each step is in compliance
to the standards.
Description:
we can offer you customized service, the following items are optional: Container mast, for example, 2-stage full free mast of 3m, 3-stage full free mast of 4.5m/ 4.8m side shifter, fork positioner, longer forks, fork extension and all kinds of forklift attachment. For the details of customized configurations and options, please contact with us.
Standard Configuration
Hydraulic Automatic Transmission.
Shimadzu's Pump Valve, Eaton Pipe and NOK Hydraulic Cyr Seals.
Electric-hydraulic Directional Control Valve.
The Casting-type Steering Axle which more than 8 years of service life than ordinary Welded Axle.
The Maintenance Free Radiators adopt Germany Technology.
Adopt Priority Steering System, which improve the work efficiency.
Original Toyota Comfortable Seat with Armrest and Safe-belt, LED Light ect.
Thicker reinforcing overhead guard protective device, ensure the safety.
Middle muffler, more environmental.
Technical Parameter:
Type | CPD1030 | CPD1530 | CPD2030 | CPD3030 |
Capacity(kg) | 1000 | 1500 | 2000 | 3000 |
Lift Height(mm) | 3000 | 3000 | 3000 | 3000 |
Fork Length(mm) | 500 | 500 | 500 | 500 |
Min Ground Height(mm) | 1070 | 1070 | 1070 | 1070 |
Manipulation | Steering Wheel | |||
Tire | Solid Core Tire | |||
Drive wheel dimensions | 510mm | 510mm | 560mm | 650mm |
Full Load Travel Speed | 15km /h | 15km /h | 15km /h | 15km /h |
Full Load Lifting Speed | 200mm/Min. | 200mm/Min. | 200mm/Min. | 200mm/Min. |
Type of driver | Stepless speed regulation | |||
Door Frame Angle | 3-6 | 3-6 | 3-6 | 3-6 |
Full Load Climbing | 15 | 15 | 15 | 15 |
Battery (Vol./Cap.) (V /Ah) | 48/240 | 48/270 | 48/270 | 48/420 |
Reference Usage Time(h) | 3 | 3 | 3.5 | 6 |
Driving Motor(kw) | 4 | 4.2 | 5 | 8 |
Lifting Motor(kw) | 3 | 3 | 5.5 | 5.5 |
Mini. outside Turning Radius | 2000mm | 2000mm | 2100mm | 2150mm |
Dimension L×W×H(mm) | 3380×1050×2100 | 3380×1050×2100 | 3450×1100×2100 | 3600×1160×2120 |
Net Weight(kg) | 2200 | 2000 | 2100 | 2150 |
Lifting Height of Each Cap. Corresponding Height of Gantry | 1600/2000/2500/3000/3500mm 2080/1600/1850/2080/2350mm | |||
CPD Electric Forklift Large Wheel Forklift Full Electric Pallet with Electric Forklift Truck Price
| Product Name | CPD Electric Forklift Large Wheel Forklift Full Electric Pallet with Electric Forklift Truck Price |
| Features | Good quality and low price |
| Service | OEM&ODM |
| Custom Design | Welcome |
| Sample Lead Time | 5~40Days |
| Payment Terms | 30% advance payment, the rest payment before delivery |
| Market | all over the world |
| Form of sale | Factory supply |
Q1:How do you control the quality?
A:We have QC team comply with TQM,each step is in compliance to the standards.At the same time,they
will take photos and shoot video for you.
Q2:Why should I choose your company?
A:1,We have own logistics who cooperate different forwarders at the ports of destination.It's good for you
to do DDP or DDU.
A2:We have own warehouse at the ningbo port China.
If you want to mix disparate products to different stores,we can help you to finish the work when our
workers receive the goods from suppliers. New carton labels will be printed and new pallets with unique
IDs will be created.It will save labor cost for you.
Q3: Can you print our brand on the product?
A: Yes, Of course. It can make customer’s brand logo.
Q4: What is your terms of packing?
A: Generally, we pack our goods in neutral cartons. If you have legally registered patent, we can pack the
goods by your logo after getting your authorization letters.
Q5: What about the Wheel axle scales price?
A: We promise the Wheel axle scales price we offer is lowest if same application, only to enlarge the
market share.
Q6:What’s your company payment terms?
A:L/C at sight/ 30days, T/T 30%deposit 70% before shipment.
Q7:Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery. We have QC team comply with TQM,each step is in compliance
to the standards.
