SAINTBOND Wireless Load Cell Sensor
LL01W Wireless Load Cell Sensor
18650 rechargeable batteries or polymer batteries
LED
Wireless Load Cell Sensor
2 Pcs
Welcome
OEM&ODM
OEM & ODM Manufacture
45 -50DAYS
15~30Days
15 years experience on Load Cell
High performance wireless load link instrument 500 ton electronic wireless Load Cell Sensor
Dimensions shown are nominal and subject to tolerances
Model | Cap. | Div | A | B | C | D | φ | H | Material |
(Kg) | (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | |||
LL01-01 | 1t | 0.5 | 245 | 112 | 37 | 190 | 43 | 335 | Aluminum |
LL01-02 | 2t | 1 | 245 | 116 | 37 | 190 | 43 | 335 | Aluminum |
LL01-03 | 3t | 1 | 260 | 123 | 37 | 195 | 51 | 365 | Aluminum |
LL01-05 | 5t | 2 | 285 | 123 | 57 | 210 | 58 | 405 | Aluminum |
LL01-10 | 10t | 5 | 320 | 120 | 57 | 230 | 92 | 535 | Alloy Steel |
LL01-20 | 20t | 10 | 420 | 128 | 74 | 260 | 127 | 660 | Alloy Steel |
LL01-30 | 30 | 10 | 420 | 138 | 82 | 280 | 146 | 740 | Alloy Steel |
LL01-50 | 50t | 20 | 465 | 150 | 104 | 305 | 184 | 930 | Alloy Steel |
LL01-100 | 100t | 50 | 570 | 190 | 132 | 366 | 229 | 1230 | Alloy Steel |
LL01-200 | 200t | 100 | 725 | 265 | 183 | 440 | 280 | 1380 | Alloy Steel |
LL01R-250 | 250t | 100 | 800 | 300 | 200 | 500 | 305 | 1880 | Alloy Steel |
LL01R-300 | 300t | 200 | 880 | 345 | 200 | 500 | 305 | 1955 | Alloy Steel |
LL01R-500 | 550t | 200 | 1000 | 570 | 200 | 500 | 305 | 2065 | Alloy Steel |
Wireless Load Links Typical Specifications:
Rate Load: | 1/205/5/12/25/35/50/75/100/150/200/250/300/500T | ||
Battery Type: | 18650 rechargeable batteries or polymer batteries (7.4v 2000 Mah) | ||
Proof Load: | 150% of rate load | Max. Safety Load: | 125% F.S. |
Ultimate Load: | 400% F.S. | Battery Life: | ≥40 hours |
Power On Zero Range: | 20% F.S. | Operating Temp.: | - 10℃ ~ + 40℃ |
Manual Zero Range: | 4% F.S. | Operating Humidity: | ≤85% RH under 20℃ |
Tare Range: | 20% F.S. | Remote Controller Distance: | Min.15m |
Stable Time: | ≤10seconds; | System Range: | 500~800m |
Overload Indication: | 100% F.S. + 9e | Telemetry Frequency: | 470mhz |
High performance wireless load link instrument 500 ton electronic wireless Load Cell Sensor
Dimensions shown are nominal and subject to tolerances
Model | Cap. | Div | A | B | C | D | φ | H | Material |
(Kg) | (mm) | (mm) | (mm) | (mm) | (mm) | (mm) | |||
LL01-01 | 1t | 0.5 | 245 | 112 | 37 | 190 | 43 | 335 | Aluminum |
LL01-02 | 2t | 1 | 245 | 116 | 37 | 190 | 43 | 335 | Aluminum |
LL01-03 | 3t | 1 | 260 | 123 | 37 | 195 | 51 | 365 | Aluminum |
LL01-05 | 5t | 2 | 285 | 123 | 57 | 210 | 58 | 405 | Aluminum |
LL01-10 | 10t | 5 | 320 | 120 | 57 | 230 | 92 | 535 | Alloy Steel |
LL01-20 | 20t | 10 | 420 | 128 | 74 | 260 | 127 | 660 | Alloy Steel |
LL01-30 | 30 | 10 | 420 | 138 | 82 | 280 | 146 | 740 | Alloy Steel |
LL01-50 | 50t | 20 | 465 | 150 | 104 | 305 | 184 | 930 | Alloy Steel |
LL01-100 | 100t | 50 | 570 | 190 | 132 | 366 | 229 | 1230 | Alloy Steel |
LL01-200 | 200t | 100 | 725 | 265 | 183 | 440 | 280 | 1380 | Alloy Steel |
LL01R-250 | 250t | 100 | 800 | 300 | 200 | 500 | 305 | 1880 | Alloy Steel |
LL01R-300 | 300t | 200 | 880 | 345 | 200 | 500 | 305 | 1955 | Alloy Steel |
LL01R-500 | 550t | 200 | 1000 | 570 | 200 | 500 | 305 | 2065 | Alloy Steel |
Wireless Load Links Typical Specifications:
Rate Load: | 1/205/5/12/25/35/50/75/100/150/200/250/300/500T | ||
Battery Type: | 18650 rechargeable batteries or polymer batteries (7.4v 2000 Mah) | ||
Proof Load: | 150% of rate load | Max. Safety Load: | 125% F.S. |
Ultimate Load: | 400% F.S. | Battery Life: | ≥40 hours |
Power On Zero Range: | 20% F.S. | Operating Temp.: | - 10℃ ~ + 40℃ |
Manual Zero Range: | 4% F.S. | Operating Humidity: | ≤85% RH under 20℃ |
Tare Range: | 20% F.S. | Remote Controller Distance: | Min.15m |
Stable Time: | ≤10seconds; | System Range: | 500~800m |
Overload Indication: | 100% F.S. + 9e | Telemetry Frequency: | 470mhz |
