SAINTBOND Wireless Tension Load Cell
LC220WA Wireless Tension Load Cell
18650 rechargeable batteries or polymer batteries
LED
Wireless Tension Load Cell
2 Pcs
Welcome
OEM&ODM
OEM & ODM Manufacture
45 -50DAYS
15~30Days
15 years experience on Load Cell
IP68 5/50/100/300/500T Digital Dynamometer Wireless Tension Load Cell
Cap./t | H | W | L | L1 | A |
1~5t | 76 | 34 | 230 | 160 | 38 |
7.5~10t | 90 | 47 | 280 | 180 | 40 |
20~30t | 125 | 55 | 370 | 230 | 53 |
40~60t | 150 | 85 | 430 | 254 | 73 |
80~150t | 220 | 115 | 580 | 340 | 98 |
200t | 265 | 183 | 725 | 390 | 280 |
250t | 300 | 200 | 800 | 425 | 305 |
300t | 345 | 200 | 875 | 460 | 305 |
500t | 570 | 200 | 930 | 510 | 30 |
Wireless Load Links Typical Specifications:
Rate Load: | 1/5/10/20/30/50/80/100/150/200/250/300/500T | ||
Battery Type: | 18650 rechargeable batteries or polymer batteries (7.4v 2000 Mah) | ||
Proof Load: | 150% of rate load | Max. Safety Load: | 125% F.S. |
Ultimate Load: | 400% F.S. | Battery Life: | ≥40 hours |
Power On Zero Range: | 20% F.S. | Operating Temp.: | - 10℃ ~ + 40℃ |
Manual Zero Range: | 4% F.S. | Stable Time: | ≤10seconds; |
Tare Range: | 20% F.S. | Remote Controller Distance: | Min.15m |
Operating Humidity: | ≤85% RH under 20℃ | System Range: | 500~800m (In Open Area) |
Overload Indication: | 100% F.S. + 9e | Telemetry Frequency: | 470mhz |
Available Options:
Hazardous area Zone 1 and 2
Built-in-display option
Available with a range of displays to suit each application
Environmentally sealed to IP67 or IP68
Can be used singularly or in sets
FAQ:
Q: Could you offer more information about the products, and quote a best price ?
A: Yes, certainly, we will send our product catalogue and company introduction for your reference.
You can choose one or some model, I will advice suitable one for you, also with best price details.
Q: Are you manufacture or trading company ?
A: We are manufacture, also have own export right under our export company. Welcome to visit our factory, check our quality and service.
Q: How long is your delivery time ? What's your payment terms ?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity. Payment terms is TT, LC, Cash, also can be negotiation with us.
Q: Your price is a little bit higher than my target, can you offer a better price ?
A: Yes, price can be negotiation, we try our best to meet your target, let's find a win-win solution, we always keep long term cooperation relations with customers.
IP68 5/50/100/300/500T Digital Dynamometer Wireless Tension Load Cell
Cap./t | H | W | L | L1 | A |
1~5t | 76 | 34 | 230 | 160 | 38 |
7.5~10t | 90 | 47 | 280 | 180 | 40 |
20~30t | 125 | 55 | 370 | 230 | 53 |
40~60t | 150 | 85 | 430 | 254 | 73 |
80~150t | 220 | 115 | 580 | 340 | 98 |
200t | 265 | 183 | 725 | 390 | 280 |
250t | 300 | 200 | 800 | 425 | 305 |
300t | 345 | 200 | 875 | 460 | 305 |
500t | 570 | 200 | 930 | 510 | 30 |
Wireless Load Links Typical Specifications:
Rate Load: | 1/5/10/20/30/50/80/100/150/200/250/300/500T | ||
Battery Type: | 18650 rechargeable batteries or polymer batteries (7.4v 2000 Mah) | ||
Proof Load: | 150% of rate load | Max. Safety Load: | 125% F.S. |
Ultimate Load: | 400% F.S. | Battery Life: | ≥40 hours |
Power On Zero Range: | 20% F.S. | Operating Temp.: | - 10℃ ~ + 40℃ |
Manual Zero Range: | 4% F.S. | Stable Time: | ≤10seconds; |
Tare Range: | 20% F.S. | Remote Controller Distance: | Min.15m |
Operating Humidity: | ≤85% RH under 20℃ | System Range: | 500~800m (In Open Area) |
Overload Indication: | 100% F.S. + 9e | Telemetry Frequency: | 470mhz |
Available Options:
Hazardous area Zone 1 and 2
Built-in-display option
Available with a range of displays to suit each application
Environmentally sealed to IP67 or IP68
Can be used singularly or in sets
FAQ:
Q: Could you offer more information about the products, and quote a best price ?
A: Yes, certainly, we will send our product catalogue and company introduction for your reference.
You can choose one or some model, I will advice suitable one for you, also with best price details.
Q: Are you manufacture or trading company ?
A: We are manufacture, also have own export right under our export company. Welcome to visit our factory, check our quality and service.
Q: How long is your delivery time ? What's your payment terms ?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity. Payment terms is TT, LC, Cash, also can be negotiation with us.
Q: Your price is a little bit higher than my target, can you offer a better price ?
A: Yes, price can be negotiation, we try our best to meet your target, let's find a win-win solution, we always keep long term cooperation relations with customers.
