Wireless Dyna-Link Load Cells 500T Waterproof Remote Displayer Wireless Digital Dynamometer

Model

Cap.

Div

A

B

C

D

φ

H

Material

(Kg)

(mm)

(mm)

(mm)

(mm)

(mm)

(mm)

CS-SW6-01

1t

0.5

245

112

37

190

43

335

Aluminum

CS-SW6-02

2t

1

245

116

37

190

43

335

Aluminum

CS-SW6-03

3t

1

260

123

37

195

51

365

Aluminum

CS-SW6-05

5t

2

285

123

57

210

58

405

Aluminum

CS-SW6-10

10t

5

320

120

57

230

92

535

Alloy Steel

CS-SW6-20

20t

10

420

128

74

260

127

660

Alloy Steel

CS-SW6-30

30

10

420

138

82

280

146

740

Alloy Steel

CS-SW6-50

50t

20

465

150

104

305

184

930

Alloy Steel

CS-SW6-100

100t

50

570

190

132

366

229

1230

Alloy Steel

CS-SW6-200

200t

100

725

265

183

440

280

1380

Alloy Steel

CS-SW6R-250

250t

100

800

300

200

500

305

1880

Alloy Steel

CS-SW6R-300

300t

200

880

345

200

500

305

1955

Alloy Steel

CS-SW6R-500

550t

200

1000

570

200

500

305

2065

Alloy Steel

Model

1t

2t

3t

5t

10t

20t

30t

Weight(kg)

1.6

1.7

2.1

2.7

10.4

17.8

25

Weight with shackles(kg)

3.1

3.2

4.6

6.3

24.8

48.6

87

Model

50t

100t

200t

250t

300t

500t

Weight(kg)

39

81

210

280

330

480

Weight with shackles(kg)

128

321

776

980

1500

2200

Rate Load:

1/205/5/12/25/35/50/75/100/150/200/250/300/500T

Battery Type:

18650 rechargeable batteries or polymer batteries (7.4v 2000 Mah)

Proof Load:

150% of rate load

Max. Safety Load:

125% F.S.

Ultimate Load:

400% F.S.

Battery Life:

≥40 hours

Power On Zero Range:

20% F.S.

Operating Temp.:

- 10℃ ~ + 40℃

Manual Zero Range:

4% F.S.

Operating Humidity:

≤85% RH under 20℃

Tare Range:

20% F.S.

Remote Controller Distance:

Min.15m

Stable Time:

≤10seconds;

System Range:

500~800m

Overload Indication:

100% F.S. + 9e

Telemetry Frequency:

470mhz
