SAINTBOND
Load Cell Amplifier
Home Amplifier
2 (2.0)
Zhejiang, China
Strain Gauge Transducer Amplifiers
Plastic
LED/LCD
AC/DC Adaptor 12V or Rechargeable battery
OEM&ODM
Carton,0.35x0.3x0.2cm
OEM/ODM
for sensors Load Cell Gauge Transducer Amplifiers Strain gage amplifier
Product Overview:
The transmitter (transmitter) is the output signal of the load cell can be changed into the identification signal controller (or load cell input into electrical signals and amplifies the signal source for remote measurement and control) converter. Sensors and transmitters form an automatic control monitoring signal source. Different physical quantities require different sensors and corresponding transmitters. There are many kinds of transmitters.Transmitters used in industrial instruments include temperature transmitters, pressure transmitters, flow transmitters, current transmitters, voltage transmitters, and so on.The design and design of this product take into account the requirements of long-term stability and anti-interference in the field of industrial control. In anti-interference, stability and other aspects have made enhanced improvement, this product can be better used in industrial control areas and other analog output of the harsh occasions.
| Product name | for sensors Load Cell Gauge Transducer Amplifiers Strain gage amplifier |
| Model | Load Cell Amplifier |
| Brand | SAINTBOND |
| Market | all over the world |
| Materials | Plastic |
| Power supply | AC/DC Adaptor 12V or Rechargeable battery |
| Advantage | OEM/ODM |
| Sample Lead Time | 3~5Days |
| Sample price | the price is different according to product capacity |
| MOQ | 1PCS |
| Custom Design | Welcome |
| Payment Terms | 30% advance payment, the rest payment before delivery |
| Form of sale | Factory supply |
Product Features:
1: The shell and wire joint are waterproof design, good sealing, suitable for harsh environment
2: Plastic shell, durable
3: High precision operational amplifier circuit, high accuracy, good stability
4: Power supply has reverse connection protection, surge protection and over-current protection function
5: It is suitable for weighing, pulling, pressure, torque and other strain load cell
Technical Parameter:
1: operating voltage: 24VDC
2: output signal: 0-5V, 0-10V, 4-20mA
3: operating temperature range: -20-60 DEG C
4: working environment humidity: 10%RH-90%RH (without condensation)
5: accuracy: better than 0.2%F.S.
Products Type:
4-20mA
0-5V
0-10V
Connection Mode:
Input signal wiring identifier | S(IN)+ | S(IN)- | V(8V)+ | V(GND)- | GNDD | |
Connection definition | Signal+ | Signal- | Excitation + | Excitation - | Shield | |
Input signal wiring identifier | 24V+ | GND | Iout | GNDD | ||
Connection definition | Power+ | Power- | Output Signal | Shield | ||
Debugging:
1.Zero adjustment
First of all, the system is in the no-load state, adjust the mark "ZERO" potentiometer to adjust the bias. Measure the output current or voltage with a multimeter, so that the indication is as close as possible to the zero point. Otherwise, when the magnification is changed, the zero point changes will become larger.
2.Gain adjustment
The system load weight (recommended value range: 80%~100%FS), to calculate the output current value according to the loading weight and weighing value ratio, digital multimeter monitoring output potentiometer to adjust the gain of the amplifier rotation mark "SPAN".
3.Re-examination
The system is in no-load state, measuring the output of zero point, loading a certain weight, measuring whether the output voltage is in line with the expected magnification. If not, repeat steps 1 and 2 again.
FAQ:
Q: Could you offer more information about the products, and quote a best price ?
A: Yes, certainly, we will send our product catalogue and company introduction for your reference.
You can choose one or some model, I will advice suitable one for you, also with best price details.
Q: Are you manufacture or trading company ?
A: We are manufacture, also have own export right under our export company. Welcome to visit our factory, check our quality and service.
Q: How long is your delivery time ? What's your payment terms ?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity. Payment terms is TT, LC, Cash, also can be negotiation with us.
Q: Your price is a little bit higher than my target, can you offer a better price ?
A: Yes, price can be negotiation, we try our best to meet your target, let's find a win-win solution, we always keep long term cooperation relations with customers.
