Zhejiang, China
Saintbond
TSensor006
Weigh the weight of the weigher
Convert electrical signal to the force signal
0-10MV
Web Chain Tension Control Force Measuring Sensors
Alloy / Stainless Steel
Customizable
Good quality and low price
0.35x0.3x0.2cm
5~40Days
Welcome
1PCS
All over the world
Factory supply
Web Chain Tension Control Force Measuring Sensors
An excellent "TSensor006 series axis desktop tension sensor adopts the advanced sensor technology, sealing and anti corrosion design and monolithic sensor structure of the frequency response is improved greatly, the output signal has good linearity and fast response characteristics, to ensure zero absolutely reply. TSensor006 series of tension sensor strong and durable, anti-corrosion and dust, high stability. The foil strain gauge can provide high sensitivity and no internal temperature compensation network under low tension. Using separate installation, greatly simplify the installation process. TSensor006 series tension sensor has a variety of specifications and installation method, which is widely used in the printing, composite, coating, cutting, paper, rubber, textile, wire and cable and film roll control equipment and production line.
Type | Dimension(mm) | ||||||||||||
| A | B | C | D | E | F | G | H | N | O | U | V | W |
TSensor006-M1 | 76 | 228 | 72 | 65 | 88 | 12 | 203 | 178 | M10 | 12 | 44 | 70 | --- |
TSensor006-M2 | 114 | 343 | 111 | 103 | 126 | 25 | 311 | 279 | --- | 13 | --- | --- | 70 |
TSensor006-M3 | 75 | 400 | 149 | 108 | 87 | 30 | 360 | 300 | --- | 13 | --- | --- | 70 |
TSensor006 series axle-table tension sensor adopts advanced sensor technology of the United States, fully sealed anti-corrosion design, integral sensor structure makes its response frequency greatly increased, the output signal has the characteristics of good linearity and fast response, and ensures zero-point recovery. TSensor006 series tension sensor is durable, anti-corrosion, dust-proof and high stability. The foil strain gauge can still provide high sensitivity under low tension without the need for built-in temperature compensation network. Separate installation greatly simplifies the installation process. TSensor006series tension sensors have many specifications and installation methods, and are widely used in coiling control equipment and production lines such as printing, composite, coating, shearing, paper making, rubber, textile, wire, cable and film.
TSensor006-M1 | 500/1000/2500/5000 | ||
TSensor006-M2 | 5000/12500/25000/40000/50000 | ||
TSensor006-M3 | 80000/100000(Customizable) | Linear Error: | <±0.1% |
Power Supply: | DC5-15V | Repeatability Error: | <±0.1% |
Output Signal: | 0-20mA/4-20mA | Combined Error: | <±0.1% F.S |
Temp. Drift | <±0.02%℃ | Operating Temp. Range: | -38~+75℃ |
Joint Specification: | Aviation plugs-12 | Working humidity Range: | <90%R.H. |
FAQ:
Q: Could you offer more information about the products, and quote a best price ?
A: Yes, certainly, we will send our product catalogue and company introduction for your reference.
You can choose one or some model, I will advice suitable one for you, also with best price details.
Q: Are you manufacture or trading company ?
A: We are manufacture, also have own export right under our export company. Welcome to visit our factory, check our quality and service.
Q: How long is your delivery time ? What's your payment terms ?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity. Payment terms is TT, LC, Cash, also can be negotiation with us.
Q: Your price is a little bit higher than my target, can you offer a better price ?
A: Yes, price can be negotiation, we try our best to meet your target, let's find a win-win solution, we always keep long term cooperation relations with customers.
